Sikafloor® Marine-107
Ultra lightweight self-leveling primary deck covering mortar for interior decks
Sikafloor® Marine-107 is a 1-component ultra-light weight self-leveling mortar based on polymer modified cement. Sikafloor® Marine-107 is tested according to FTP Code system and approved according to the IMO Marine Equipment Directives.
- Ultra-light weight leveling mortar
- Good leveling properties in thin layers
- Can be pumped
- One component, ready to mix
- Easy to apply
PRODUCT BENEFITS
- Ultra-light weight leveling mortar
- Good leveling properties in thin layers
- Can be pumped
- One component, ready to mix
- Easy to apply
Areas of Application
Sikafloor® Marine-107 is applied on interior decks, to level the surface prior to the application of deck finishing materials such as carpets and vinyl. It is suitable for application in throughout the accommodation areas. This product is suitable for experienced professional users only. Test with actual substrates and conditions have to be performed to ensure adhesion and material compatibility.Packaging
Bag | 12 kg |
Product Details
Chemical base | Polymer modified cement mortar | |
Color | Grey | |
Cure mechanism | Hydraulic | |
Density | fresh cured | 1 kg/l 0.7 kg/l |
Mixing ratio | per 12 kg bag | 6.5 ─ 6.8 liters |
Substrate temperature | 5 ─ 30 °C | |
Coverage | per 12 kg bag at layer thickness 1 mm | 17 m2 |
Working time (CQP599-9) | 20 minutes A | |
Ready to walk on (CQP600-3) | depending on humidity and ventilation | 3 hours A |
Compressive strength (CQP599-2) | 11 MPa B | |
Flexural strength (CQP599-1) | 3 MPa B | |
Modulus of elasticity in compression (CQP599-6 / EN 13412) | 3 GPa B | |
Linear shrinkage (CQP599-5) | 0.03 % B | |
Shelf life | 12 months C |
CQP = Corporate Quality Procedure | A) 23 °C / 50 % r. h. | B) after 28 days | C) stored in a dry, cool place below 25 °C |
CURE MECHANISM
Sikafloor® Marine-107 cures by way of hydraulic curing.
Application
Surface preparation
For leveling applications, the surface has to be clean, free from dust, grease, oils and other substances, which may impair adhesion. Rust has to be removed with a steel brush or other appropriate means, followed by vacuum cleaning.
The surface has to be primed with Sikafloor® Marine Primer C using a long hair roller. After drying of the Sikafloor® Marine Primer C, Sikafloor® Marine-107 may be applied.
Sikafloor® Marine-107 applications on aluminum or zinc rich shop primer coated decks, require a tie coat of SikaCor® ZP Primer or another suitable tie coat prior the priming step with Sikafloor® Marine Primer C.
Application
Apply the mortar with a steel board or a straight edge. Sikafloor® Marine-107 can also be applied by pinrake.
Sikafloor® Marine-107 has to be applied within 20 minutes after mixing. At temperatures above 30 °C the open time will be reduced to 10 minutes or less.
If applied in thickness less than 3 mm the self-levelling capability will be reduced.
For advice on selecting and setting up a suitable pump system, contact the System Engineering Department of Sika Industry.
Curing
After application, the finished areas have to be protected against direct heat (e.g. cutting or welding from beneath), sunlight and draught during the curing process for at least 12 hours.
Before Sikafloor® Marine-107 is covered with dense materials such as vinyl, etc., ensure that the remaining moisture level is below 4 %.
Test procedure to determine the dryness (according ASTM D 4263): put a PE-plastic foil 1 m x 1 m on the surface of the applied mortar floor, tape the perimeter and leave for one day. The curing is complete if there is no water condensation on the foil or a visible color difference between covered and uncovered surface.
Removal
Excess material can best be removed before curing with a trowel wipe or water.
Fresh Sikafloor® Marine-107 may be removed from tools and equipment with water. Once cured, the material can only be removed mechanically.
Exposed hands and skin shall be washed immediately with water. Use a suitable skin protection hand cream.
Application limits
For applications on slooping surfaces > 1 % contact the Technical Department of Sika Industry.
