SikaBlock® M150
Polyurethane design board
SikaBlock® M150 is a polyurethane design board for manufacture of styling models and design studies.
- Easy workable
- Very low thermal expansion
- Good adhesion of putties
Polyurethane design board
SikaBlock® M150 is a polyurethane design board for manufacture of styling models and design studies.
Dimensions [mm] | Pcs./pallet |
2000 x 1000 x 100 2000 x 1000 x 150 2000 x 1000 x 200 2000 x 1000 x 250 2000 x 1000 x 300 2000 x 1000 x 400 | 12 8 6 5 4 3 |
Chemical base | Polyurethane | |
Color | Light green | |
Density | 0.15 kg/l | |
Compressive strength (ISO 844) | 1.6 MPa | |
Flexural strength (CQP027-2 / ISO 178) | 2.2 MPa | |
Flexural modulus (CQP027-2 / ISO 178) | 65 MPa | |
Thermal conductivity (ASTM C-518) | 0.032 W/(m·K) | |
Linear coefficient of thermal expansion (CQP053-1 / ISO 11359) | 60 x 10-6 1/K | |
Service temperature | -60 ─ 80 °C |
CQP = Corporate Quality Procedure |
SikaBlock® M150 can be easily machined by milling, drilling, sawing or modified manually. It is recommended to use high performance tools to machine these boards.
For milling parameters check information from cutting tool manufacturers or get the General Guideline “Milling parameters for SikaBlock®” for more general information.
The board needs to be stored flat over the entire surface in dry conditions.
Many models and tools are made of bonded boards, either with identical or other materials. Storage at low and elevated temperature can lead to high stresses due to the different expansion coefficients. To prevent this, it is necessary to store the models and tools at a temperature range between 15 °C and 30 °C.
